7-15
Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE for Cisco Unified Communications Manager 6.1
OL-14620-01
Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
Expansion Module Status Screen (SCCP Phones Only)
The Expansion Module Status screen displays information about each
Cisco
Unified IP Phone Expansion Module 7914 that is connected to the phone.
Table 7-5 explains the information that is displayed on this screen for each
connected expansion module. You can use this information to troubleshoot the
expansion module, if necessary. In the Expansion Module Stats screen, a statistic
preceded by “A” is for the first expansion module. A statistic preceded by “B” is
for the second expansion module.
To display the Expansion Module Stats screen, follow these steps:
Procedure
Step 1 Press the Settings button.
Step 2 Select Status.
Step 3 Select Expansion Module.
Ta b l e 7-4 Firmware Version Information
Item Description
Load File Load file running on the phone
App Load ID Identifies the JAR file running on the phone
JVM Load ID Identifies the Java Virtual Machine (JVM) running
on the phone
OS Load ID Identifies the operating system running on the phone
Boot Load ID Identifies the factory-installed load running on the
phone
DSP Load ID Identifies the digital signal processor (DSP) software
version used
Expansion Module 1
Expansion Module 2
Identifies the load running on the Expansion
Module(s), if connected to the phone
