Cisco PIX 501 Hardware Installation Guide

CHAPTER
2-1
Cisco PIX Firewall Hardware Installation Guide
78-15170-01
2
PIX 501
This chapter describes how to install a PIX 501, and includes the following sections:
• PIX 501 Product Overview, page 2-1
• Installing the PIX 501, page 2-3
• Connecting a Power Supply Module to the PIX 501, page 2-3
PIX 501 Product Overview
This section describes the PIX 501 front and rear panels and the panel LEDs.
Note The PIX 501 chassis cover should not be removed as it does not contain user-serviceable components.
Figure 2-1 shows the front view of the PIX 501.
Figure 2-1 PIX 501 Front Panel
67848
POWER
VPN TUNNEL
LINK/ACT
100 MBPS
1234
CISCO
PIX
®
501
FIREWALL
