Cisco PIX 501 Hardware Installation Guide

CHAPTER
3-1
Cisco PIX Firewall Hardware Installation Guide
78-15170-01
3
PIX 506/506E
This chapter describes how to install a PIX 506/506E, and includes the following sections:
• PIX 506/506E Product Overview, page 3-1
• Installing the PIX 506/506E, page 3-4
• Connecting a Power Supply Module to the PIX 506/506E, page 3-5
The PIX 506 and the PIX 506/506E are the same except the PIX 506/506E has a faster processor and
a different power supply.
PIX 506/506E Product Overview
This section describes the PIX 506/506E front and rear panels and the panel LEDs.
Note The PIX 506/506E chassis cover should not be removed as it does not contain user-serviceable
components.
Figure 3-1
shows the front view of the PIX 506.
Figure 3-1 PIX 506 Front Panel
67944
POWER
ACT
NETWORK
CISCO SECURE PIX 506
FIR
EW
A
LL
