Configuring IP Information
Configuring ARP
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 224
16
DHCP Relay Description
DHCP Relay Limitations
Defining DHCP Relay Properties
Defining DHCP Relay Interfaces
Configuring ARP
The switch maintains an ARP (Address Resolution Protocol) table for all known
devices that reside in its directly-connected IP subnets. A directly-connected IP
subnet is the subnet to which a IPv4 interface of the switch is connected. When the
switch needs to send/route a packet to a local device, it searches the ARP table to
obtain the MAC address of the device. The ARP table contains both static and
dynamic addresses. Static addresses are manually configured and do not age out.
The switch creates dynamic addresses from the ARP packets it receives. Dynamic
addresses age out after a configured time.
NOTE The IP/MAC address mapping information in the ARP Table is used by the switch to
forward traffic originated by the switch.
To define the ARP tables:
STEP 1 Click IP Configuration > ARP (Layer 2) . The ARP Table page opens.
STEP 2 Enter the parameters.
• ARP Entry Age Out—Enter the number of seconds that dynamic addresses
can remain in the ARP table. A dynamic address ages out after the time it is
in the table exceeds the ARP Entry Age Out time. When a dynamic address
ages out, it is deleted from the table, and only returns when it is relearned.
• Clear ARP Table Entries—Select the type of ARP entries to be cleared from
the system.
-
All
—Deletes all of the static and dynamic addresses immediately.
-
Dynamic
—Deletes all of the dynamic addresses immediately.
-
Static
—Deletes all of the static addresses immediately.
