Port Management
Configuring Link Aggregation
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 91
8
To define the member or candidate ports in a LAG.
STEP 1 Select the LAG to be configured, and click Edit. The Edit LAG Membership page
opens.
STEP 2 Enter the values for the following fields:
• LAG—Select the LAG number.
• LAG Name—Enter the LAG name or a comment.
• LACP—Select to enable LACP on the selected LAG. This makes it a dynamic
LAG. This field can only be enabled after moving a port to the LAG in the next
field.
• Port List—Move those ports that are to be assigned to the LAG from the
Port List to the LAG Members list. Up to eight ports per static LAG can be
assigned, and 16 ports can be assigned to a dynamic LAG.
STEP 3 Click Apply. The LAG membership is defined, and the Running Configuration file is
updated.
Configuring LAG Settings
The LAG Settings page displays a table of current settings for all LAGs. You can
configure the settings of selected LAGs, and reactivate suspended LAGs by
launching the Edit LAG Settings page.
To configure the LAG settings or reactivate a suspended LAG:
STEP 1 Click Port Management > Link Aggregation > LAG Settings. The LAG Settings
page opens.
STEP 2 Select a LAG, and click Edit. The Edit LAG Settings page opens.
STEP 3 Enter the values for the following fields:
• LAG—Select the LAG ID number.
• Description—Enter the LAG name or a comment.
• LAG Type—Displays the port type that comprises the LAG.
• Administrative Status—Set the selected LAG to be Up or Down.
• Operational Status—Displays whether the LAG is currently operating.
