Configuring Discovery
Configuring LLDP
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 73
7
Accessing LLDP Statistics
The LLDP Statistics page displays LLDP statistical information per port.
To view the LLDP statistics:
STEP 1 Click Administration > Discovery - LLDP > LLDP Statistics. The LLDP Statistics
page opens.
For each port, the fields are displayed:
• Interface—Identifier of interface.
• Tx Frames Total—Number of transmitted frames.
• Rx Frames
-
To t a l —Number of received frames.
-
Discarded —Total number of received frames that were discarded.
-
Errors —Total number of received frames with errors.
• Rx TLVs
-
Discarded —Total number of received TLVs that were discarded.
-
Unrecognized —Total number of received TLVs that were unrecognized.
• Neighbor’s Information Deletion Count—Number of neighbor ageouts on
the interface.
STEP 2 Click Refresh to view the latest statistics.
LLDP Overloading
LLDP adds information as LLDP and LLDP-MED TLVs into the LLDP packets. LLDP
overload occurs when the total amount of information to be included in a LLDP
packet exceed the maximum PDU size supported by an interface.
The
LLDP Overloading page displays the number of bytes of LLDP/LLDP-MED
information, the number of available bytes for additional LLDP information, and the
overloading status of every interface.
