Set PC VLAN Field

Procedure

Step 1

Ensure that the Admin VLAN ID option is set.

Step 2

Scroll to the PC VLAN option and press Edit.

Step 3

Enter a new PC VLAN setting.

Step 4

Press Apply.

Step 5

Press Save.

Set SW Port Setup Field

Procedure

Step 1

Unlock network configuration options.

Step 2

Scroll to the SW Port Setup option and press Select.

Step 3

Scroll to the setting that you want and press Select.

Set PC Port Setup Field

Procedure

Step 1

Unlock network configuration options.

Step 2

Scroll to the PC Port Setup option and press Select.

Step 3

Scroll to the setting that you want and press Select.

Set DHCP Field

Procedure

Step 1

Scroll to the DHCP option.

Step 2

Press Edit.

Step 3

Press either No to disable DHCP, or press Yes to enable DHCP.

Cisco Unified IP Phone 8941 and 8945 Administration Guide for Cisco Unified Communications Manager 10.0 (SCCP

and SIP)

Configure Network Settings

Default Chapter3
