Cisco WAP150 User Manual

APPENDIX A
DeAuthentication Message Reason Codes
This appendix contains the following sections:
• Deauthentication Message Reason Codes, on page 123
• Deauthentication Reason Code Table, on page 123
Deauthentication Message Reason Codes
When a client deauthenticates from the WAP device, a message is sent to the system log. The message includes
a reason code that may be helpful in determining why a client was deauthenticated. You can view log messages
when you click System Configuration > Notification > View System Log.
For more information, see Deauthentication Reason Code Table, on page 123
Deauthentication Reason Code Table
The following table describes the deauthentication reason codes.
Table 4: Deauthentication Reason Code Table
MeaningReason code
Reserved0
Unspecified reason1
Previous authentication no longer valid2
Deauthenticated because sending station (STA) is leaving or has left Independent Basic Service Set (IBSS)
or ESS
3
Disassociated due to inactivity4
Disassociated because WAP device is unable to handle all currently associated STAs5
Class 2 frame received from nonauthenticated STA6
Class 3 frame received from nonassociated STA7
Cisco WAP150 Wireless-AC/N Dual Radio Access Point with PoE / Cisco WAP361 Wireless-AC/N Dual Radio Wall Plate Access Point with PoE
123

Cisco WAP150 Specifications

General

VLAN support	Yes
Number of users	64 user(s)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Antenna type	Internal
Placement	Table, Wall
Cable lock slot type	Kensington
Security algorithms	HTTPS, SSID, WPA, WPA2
Service Set Identifier (SSID) features	SSID broadcast on/off
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	38 mm
Width	135 mm
Weight	350 g
