Cisco WAP150 User Manual

CONTENTS
Getting Started 1
CHAPTER 1
Getting Started with the Configuration 1
Using the Access Point Setup Wizard 2
Using the Access Point Setup Wizard with mobile 4
Changing Password 6
TCP/UDP Service 6
System Status 7
Quick Start Configuration 8
Window Navigation 9
Navigation Pane 9
Management Buttons 10
Administration 11
CHAPTER 2
Firmware 11
Swapping the Firmware Image 11
HTTP/HTTPS Upgrade 12
TFTP Upgrade 12
Reboot 13
Schedule Reboot 13
Configuration Management 13
Backup Configuration Files 14
Download Configuration Files 14
Copying Configuration Files 15
Clearing Configuration Files 15
System Configuration 17
CHAPTER 3
Cisco WAP150 Wireless-AC/N Dual Radio Access Point with PoE / Cisco WAP361 Wireless-AC/N Dual Radio Wall Plate Access Point with PoE
v

Cisco WAP150 Specifications

General

VLAN support	Yes
Number of users	64 user(s)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Antenna type	Internal
Placement	Table, Wall
Cable lock slot type	Kensington
Security algorithms	HTTPS, SSID, WPA, WPA2
Service Set Identifier (SSID) features	SSID broadcast on/off
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	38 mm
Width	135 mm
Weight	350 g
