Cisco WAP150 User Manual

Step 5 Repeat steps 1 through 4 and then configure the R1 key holder in the Remote R1 Key Holder Data List. A maximum of
10 entries of R1 key holders are allowed to be configured per VAP. The key holder data is configured per VAP.
• MAC Address — Destination's VAP MAC address which is the R1 Key holder. The PMKR1 is sent in RRB PUSH
message to this AP MAC address. This MAC Address must be unique across all the VAPs.
• R1 Key Holder — The R1 key Holder ID that names the holder of PMK-R1 in the authenticator.
• RRB Key — Key used to encrypt RRM protocol messages.
After you configure the Remote Key Holder Data List settings, you can click Restore to restore the old settings,
or click Apply to save the settings. Click Cancel to go back before Fast Roaming page.
Click Apply after copying or deleting a profile.
Note
Clicking Export for selected profile/s will export only those profiles. Clicking Export with no profiles selected
will Export all the profiles.
Caution
Cisco WAP150 Wireless-AC/N Dual Radio Access Point with PoE / Cisco WAP361 Wireless-AC/N Dual Radio Wall Plate Access Point with PoE
71
Fast Roaming
Configuring Remote Key Holder List Profiles

Cisco WAP150 Specifications

General

VLAN support	Yes
Number of users	64 user(s)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Antenna type	Internal
Placement	Table, Wall
Cable lock slot type	Kensington
Security algorithms	HTTPS, SSID, WPA, WPA2
Service Set Identifier (SSID) features	SSID broadcast on/off
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	38 mm
Width	135 mm
Weight	350 g
