DIR-620 Wireless N300 Router with 3G/CDMA/LTE Support
and USB Port
User Manual
Configuring via Web-based Interface
Creating Static IPv6 or Dynamic IPv6 WAN Connection
To create a connection of the Static IPv6 or Dynamic IPv6 type, click the Add button on the Net /
WAN page. On the opened page, select the relevant value from the Connection Type drop-down
list and specify the needed values.
Figure 83. The page for creating a new Static IPv6 connection. The General settings section.
Parameter Description
General settings
Provider Leave the Manually value.
Interface
A physical or virtual interface to which the new connection will be
assigned.
Name
A name for connection for easier identification.
Enable
Select the checkbox to enable the connection.
Direction
The direction of this connection.
Page 103 of 225
