DIR-620 Wireless N300 Router with 3G/CDMA/LTE Support
and USB Port
User Manual
Configuring via Web-based Interface
IPv6 Routing
On the Advanced / IPv6 routing page, you can add static routes (routes for networks that are not
connected directly to the device but are available through the interfaces of the device) into the
system.
Figure 133. The Advanced / IPv6 routing page.
To create a new route, click the Add button. In the line displayed, you can specify the following
parameters:
Parameter Description
Destination network
A destination network to which this route is assigned. You can specify
an IPv6 address (2001:db8:1234::1) or an IPv6 address with a
prefix (2001:db8:1234::/64).
Gateway
An IPv6 address through which the destination network can be
accessed. The field is available when the <Auto> value is selected
from the Via Interface drop-down list of this line.
Metric
A metric for the route. The lower the value, the higher is the route
priority. Optional.
Via Interface
Select an interface through which the destination network can be
accessed from the drop-down list. If you have selected the <Auto>
value of this drop-down list, the router itself sets the interface on the
basis of data on connected networks.
After specifying the needed parameters, click the Apply button.
Page 169 of 225
