DIR-620 Wireless N300 Router with 3G/CDMA/LTE Support
and USB Port
User Manual
Configuring via Web-based Interface
LAN
To configure the router's local interface, proceed to the Net / LAN page.
Figure 109. Basic settings of the local interface.
If needed, edit the basic settings of the local interface.
Parameter Description
IP Address
The IP address of the router in the local subnet. By default, the
following value is specified: 192.168.0.1.
Netmask
The mask of the local subnet. By default, the following value is
specified: 255.255.255.0.
IPv6 address
The IPv6 address of the router in the local subnet. By default, the
following value is specified: fd01::1/64. The field is available
for editing, if the DHCP PD checkbox is not selected.
When needed settings are configured, click the Apply button.
In the DHCP server section, you can configure the built-in DHCP server of the router.
Figure 110. The section for configuring the DHCP server.
Page 131 of 225
