DIR-620 Wireless N300 Router with 3G/CDMA/LTE Support
and USB Port
User Manual
Configuring via Web-based Interface
Using WPS Function via Web-based Interface
To add a wireless device via the PIN method of the WPS function, follow the next steps:
1. Select the WPS Enable checkbox.
2. Click the Apply button.
3. Select the PIN value from the WPS Method drop-down list.
4. Select the PIN method in the software of the wireless device that you want to connect to the
router's WLAN.
5. Click the relevant button in the software of the wireless device that you want to connect to
the WLAN.
6. Right after that, enter the PIN code specified on the cover of the wireless device or in its
software in the PIN Code field.
7. Click the Connect button in the web-based interface of the router.
To add a wireless device via the PBC method of the WPS function, follow the next steps:
1. Select the WPS Enable checkbox.
2. Click the Apply button.
3. Select the PBC value from the WPS Method drop-down list.
4. Select the PBC method in the software of the wireless device that you want to connect to the
router's WLAN.
5. Click the relevant button in the software or press the WPS button on the cover of the
wireless device that you want to connect to the WLAN.
6. Click the Connect button in the web-based interface of the router.
Using WPS Function without Web-based Interface
You can add a wireless device to the router's WLAN without accessing the web-based interface of
the router. To do this, you need to configure the following router's settings:
1. Specify corresponding security settings for the wireless network of the router.
2. Select the WPS Enable checkbox.
3. Click the Apply button.
4. Save the settings and close the web-based interface (click the icon (Save) in the
menu displayed when the mouse pointer is over the System caption in the top left part of
the page, then click the icon (Logout)).
Page 150 of 225
