DIR-620 Wireless N300 Router with 3G/CDMA/LTE Support
and USB Port
User Manual
Configuring via Web-based Interface
Creating PPTP/L2TP + Static IP or PPTP/L2TP + Dynamic IP WAN Connection
To create a connection of the PPTP + Static IP, L2TP + Static IP, PPTP + Dynamic IP, or L2TP +
Dynamic IP type, click the Add button on the Net / WAN page. On the opened page, select the
relevant value from the Connection Type drop-down list and specify the needed values.
Figure 96. The page for creating a new PPTP + Static IP connection. The General settings section.
Parameter Description
General settings
Provider Leave the Manually value.
Interface
A physical or virtual interface to which the new connection will be
assigned.
Name A name for connection for easier identification.
Enable Select the checkbox to enable the connection.
Direction The direction of this connection.
Page 118 of 225
