D-Link DWR-933 User Manual

7D-Link DWR-933 User Manual
Section 2 - Installation
Initial Setup
Installation
This section will guide you through the installation process.
1. Lift o the back cover by using the notch on the bottom.
2. Remove the battery using the notch along the top edge of the battery bay
3. Slide the micro-SIM card bracket to the left until it clicks to unlock it, then lift it
open. Place your micro-SIM card in the tray with the notch situated at the top-right,
then close the bracket and slide it to the right until it clicks to lock it in place.
4. If you want to insert a microSD card, push the microSD card bracket down until it clicks,
then lift it open. Place the microSD card in the indentation, then close the bracket and slide it
up until it clicks to lock it in place.
5. Reinsert the battery and reattach the battery cover.
6. Connect the USB cable and plug it into the USB port of a power adapter or a PC to charge
the battery
SIM
SD

D-Link DWR-933 Specifications

General

SIM card slot	Yes
3G/4G USB modem compatibility	No
Product type	Portable router
Product color	Black
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	- Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN interface type	Not available
4G standard	LTE
3G standards	DC-HSDPA, HSPA, HSPA+, WCDMA
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPS
Number of products included	1 pc(s)
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Ethernet LAN (RJ-45) ports	0
Output current	1 A
Output voltage	5 V
Battery capacity	2800 mAh
Power source type	Battery
Battery life (max)	16 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	BSMI, RoHS
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	64 mm
Width	105 mm
Height	14 mm
Weight	140 g
