D-Link DWR-933 User Manual

35D-Link DWR-933 User Manual
Section 3 - Conguration
Router LAN Settings
This section provides conguration options for local area network (LAN) settings.
Displays your current LAN status.
LAN Setting
LAN Setting
To DHCP Service Setting
Congure DHCP
Current DHCP Service
IP Address
Subnet
IP Range
The DWR-933 has a built-in DHCP server which can assign IP addresses to
connected clients. This section shows your current settings and allows you
to congure the IP address for the DWR-933, as well as congure its DHCP
settings.
This button takes you through to DHCP settings where
you can congure your IP address and IP range.
Shows if the DHCP server is ON or OFF.
The router’s current IP address.
The subnet number that your router is using.
The range of IP Addresses that the DHCP server will
give out.
Settings

D-Link DWR-933 Specifications

General

SIM card slot	Yes
3G/4G USB modem compatibility	No
Product type	Portable router
Product color	Black
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	- Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN interface type	Not available
4G standard	LTE
3G standards	DC-HSDPA, HSPA, HSPA+, WCDMA
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPS
Number of products included	1 pc(s)
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Ethernet LAN (RJ-45) ports	0
Output current	1 A
Output voltage	5 V
Battery capacity	2800 mAh
Power source type	Battery
Battery life (max)	16 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	BSMI, RoHS
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	64 mm
Width	105 mm
Height	14 mm
Weight	140 g
