D-Link DWR-933 User Manual

34D-Link DWR-933 User Manual
Section 3 - Conguration
Wi-Fi Clients
This page shows your current client list and allows you to lter clients by host name, IP address and MAC address. This ltering option enables you to
allow or deny access to specic wireless clients. Note that the 2.4 GHz and 5 GHz radios must be congured separately, but the options are the same.
Host Name
IP Address
MAC Address
Access
A unique name for each wireless client that is connected
to your router.
The IP address of the wireless client that is connected
to your router.
The hardware address of the client’s wireless adapter.
Toggle this switch to allow or deny access to specic
clients.
Note: If you deny access to a Wi-Fi client, you will see their
MAC address in the MAC Filter on page 38. If required,
you can re-allow access to the client there.
Click Apply to save changes.
Wi-Fi 2.4/5 GHz Clients List

D-Link DWR-933 Specifications

General

SIM card slot	Yes
3G/4G USB modem compatibility	No
Product type	Portable router
Product color	Black
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	- Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN interface type	Not available
4G standard	LTE
3G standards	DC-HSDPA, HSPA, HSPA+, WCDMA
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPS
Number of products included	1 pc(s)
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Ethernet LAN (RJ-45) ports	0
Output current	1 A
Output voltage	5 V
Battery capacity	2800 mAh
Power source type	Battery
Battery life (max)	16 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	BSMI, RoHS
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	64 mm
Width	105 mm
Height	14 mm
Weight	140 g
