Configuration D-Link Web Smart Switch User Manual
2
2
7
7
Server IP Address: Specifies the IPv4 address of the system log server.
UDP Port: Specifies the UDP port to which the server logs are sent. The possible range is from 1 to 65535.
The default value is 514.
Time Stamp: Select Enabled to time stamp log messages.
Severity: Specifies the minimum severity from which warning messages are sent to the server. There are
three levels. When a severity level is selected, all severity level choices above the selection are selected
automatically. The possible levels are:
Warning - The lowest level of a device warning. The device is functioning, but an operational
problem has occurred.
Informational - Provides device information.
All - Displays all levels of system logs.
Facility: Specifies an application from which system logs are sent to the remote server. Only one facility can
be assigned to a single server. If a second facility level is assigned, the first facility is overwritten. There are
up to eight facilities can be assigned (Local 0 to Local 7).
The Time Profile window allows users to configure the time profile settings of the device.
System > Time Profile
Figure 4.24 – System > Time Profile
Profile Name: Specifies the profile name.
Time(HH MM): Specifies the Start Time and End Time.
Weekdays: Specifies the week days.
Date: Select Date and specifies the From Day and To Day of the time profile.
Click Add to create a new time profile or click Delete to delete a time profile from the table.
The Power Saving mode feature reduces power consumption automatically when the RJ-45 port is link down
or the connected devices are turned off. Less power will be consumed also when the short cable is used
(less than 20 meters).
System > Power Saving
By reducing power consumption, less heat is produced, resulting in extended product life and lower
operating costs. By default, the Cable Length Detection and Link Status Detection are Enabled. Click
Apply to make the change effective.
