Configuration D-Link Web Smart Switch User Manual
6
6
3
3
The TCP/UDP Port Priority Settings window allows user to configure the port priority.
QoS > TCP/UDP Port Priority Settings
Figure 4.71 – QoS > TCP/UDP Port Priority Settings
TCP/UDP: Specify port priority of TCP or UDP to be configured.
TCP/UDP Port (0-65535): Specify the TCP or UDP port.
Priority: Defines the priority assigned to the port. The priorities are Highest, High, Medium and Low.
Click Apply for the settings to take effect.
Use Trusted Host function to manage the switch from a remote station. You can enter up to ten designated
management stations networks by defining the IPv4 Address/Netmask as seen in the figure below. The first
thing after the function is enabled is to add your local host IP address as a trusted host. Otherwise, you may
lose the connection.
Security > Trusted Host
Figure 4.72 – Security > Trusted Host
Trusted Host: Specify the Trusted Host to be enabled or disabled. The default is disabled.
To define a management station IP setting, click the Add button and type in the IP address and Subnet mask.
Click the Apply button to save your settings. You may permit only single or a range of IP addresses by
different IP mask setting, the format can be either 192.168.1.1/255.255.255.0 or 192.168.0.1/24. Please see
the example below for permitting the IP range.
IP Address Subnet Mask Permitted IP
192.168.0.1 255.255.255.0 192.168.0.1~192.168.0.255
172.17.5.215 255.0.0.0 172.0.0.1~172.255.255.255
Click Delete to remove the IP address.
Port Security is a security feature that prevents unauthorized computers (with source MAC addresses)
unknown to the Switch prior to stopping auto-learning processing from gaining access to the network.
Security > Port Security
A given ports’ (or a range of ports') dynamic MAC address learning can be stopped such that the current
source MAC addresses entered into the MAC address forwarding table cannot be changed once the port
lock is enabled.
