MNL-00008 [5] Proprietary and Confidential Page 23 of 55
3. Grasp the lamp to be removed with both hands and press down until it clears the top
socket, then remove the lamp. Reverse the process to install lamps and grid.
Note: Please see the Lamp Inspection section on page 11, for the correct specifications of
replacement lamps and see the Recommended Maintenance Schedule section on page 48 for
instructions on how to reset the lamp age monitor.
18.0 UV Series CX and UV Series CT Information
18.1 Domestic and Non-CE Electrical Requirements
Daavlin offers the UV Series Phototherapy equipment in a variety of combinations. Units are
available with lamp quantities of 12, 16, 24, and 28 with various combinations of UVA,
Narrowband UVB, and Broadband UVB. While the type of ultraviolet lamp (UVA or UVB) does
not influence the electrical requirements, the number of lamps contained in a unit does determine
the voltage, amperage, wiring, and outlet necessary to safely support operation. Table 5
Electrical Requirements and Figure 8 NEMA Outlets on page 23 define these requirements for
each model variation in the UV Series. Follow these specifications and all national and local
electrical codes when preparing the electrical supply prior to the installation of a UV Series
Device.
Note: This unit comes equipped with a USB connection to be used to transfer and backup patient
data and to grant access to service menus with service USB key.
Note: This unit should be on a dedicated circuit.
Note: Daavlin UV Series CX and UV Series CT Phototherapy equipment contain no operator
replaceable parts.
Table 5 Electrical Requirements
