Note: Please see the Lamp Inspection section on page 11, for the correct specifications of
replacement lamps and the Recommended Maintenance Schedule section on page 48 for
instructions on how to reset the lamp age monitor.
19.0 7 Series CX and 7 Series CT Information
19.1 Electrical Requirements
Daavlin offers the 7 Series CX and 7 Series CT Phototherapy equipment with lamp quantities of
4, 6, 8, 10, and 12. Units can be equipped with UVA, Narrowband UVB, Broadband UVB, and
visible light lamps. While the type of lamp does not influence the electrical requirements, the
number of lamps contained in a unit does determine the amperage necessary to safely support
operation. The table and diagrams below define these requirements for each model variations.
All domestic 120-volt 60 hertz models require a grounded, three prong electrical outlet rated for
at least 15 amps and come equipped with a grounded, three-prong plug. Units designed for other
voltages may be shipped with no wall plug, which would then have to be locally obtained, and
require an appropriate outlet that must be installed to meet local standards and requirements. All
power cords must be an approved hospital grade cord rated 300V, 1.5mm
2
minimum. The power
cord is the main disconnect device. Each unit is equipped with an IEC 320 style power inlet,
which incorporates two, 5x20mm fuses.
Note: This unit comes equipped with a USB connection to be used to transfer and backup patient
data and to grant access to service menus with service USB key.
Note: This unit should be on a dedicated circuit and all connections for power must be grounded.
Note: Daavlin 7 Series CX and 7 Series CT Phototherapy equipment contain no operator
replaceable parts.
