MNL-00008 [5] Proprietary and Confidential Page 30 of 55
All domestic 110/120-volt 60 hertz models require a grounded, three prong electrical outlet rated
for at least 15 amps and comes equipped with a grounded, three-prong plug. Units designed for
other voltages may be shipped with no wall plug, which would then have to be locally obtained,
and require an appropriate outlet that must be installed to meet local standards and requirements.
All power cords must be an approved hospital grade cord rated 300V, 1.5mm
2
minimum. The
power cord is the main disconnect device. Each unit is equipped with an IEC 320 style power
inlet, which incorporates two, 5x20mm fuses.
Note: This unit comes equipped with a USB connection to be used to transfer and backup patient
data and to grant access to service menus with service USB key.
Note: This unit should be on a dedicated circuit.
Note: Daavlin M Series CX and M Series CT Phototherapy equipment contain no operator
replaceable parts.
20.2 Unpacking and Assembly
• Your M Series will arrive in two separate boxes. The larger of the two boxes will contain
the base of the M Series along with all of your accessories and literature. The smaller of
the two boxes will contain the hood for your M Series.
• With two people, lift the base from its box and place it wherever you intend to use the
device.
Note: Be sure to remove all of the accessories, such as the manual, power cord and
eyewear before discarding the box.
• Remove the hood from the smaller box and place it on the base with the arched openings
facing forward.
Note: There is a flange on the bottom of the hood that fits over the upper edge of the
fixture. The hood is designed to fit tightly, so it may take some pressure to seat it
properly.
