SiBE121123_A Indoor Unit
Specifications 26
Ceiling Mounted Cassette Type
50 Hz, 230 V
Note:

( ) : dimension including control box
Model
FFQ25B8V1B, FFQ25B9V1B FFQ35B8V1B, FFQ35B9V1B
Cooling Heating Cooling Heating
Rated Capacity 2.5 kW Class 3.5 kW Class
Decoration
Panel
Model BYFQ60B8W1 BYFQ60B8W1
Color White White
Dimensions (H × W × D) mm 55 × 700 × 700 55 × 700 × 700
Weight (Mass) kg 2.7 2.7
Airflow Rates
H
m³/min
(cfm)
9.0 (318) 9.0 (318) 10.0 (353) 10.0 (353)
L 6.5 (230) 6.5 (230) 6.5 (230) 6.5 (230)
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Running Current (Rated) A 0.37 0.32 0.40 0.36
Power Consumption (Rated) W 73 64 84 76
Power Factor (Rated) % 85.8 87.0 91.3 91.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D)

mm 260 (286) × 575 × 575 260 (286) × 575 × 575
Packaged Dimensions (H × W × D) mm 370 × 687 × 674 370 × 687 × 674
Weight (Mass) kg 17.5 17.5
Gross Weight (Gross Mass) kg 21 21
Sound
Pressure
Level
H / L dB(A) 29.5 / 24.5 32.0 / 25.0
Sound Power Level dB 46.5 49.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm VP20 (O.D
φ
26 / I.D
φ
20) VP20 (O.D
φ
26 / I.D
φ
20)
Drawing No. 3D060405 3D060407
Model
FFQ50B8V1B, FFQ50B9V1B
Cooling Heating
Rated Capacity 5.0 kW Class
Decoration
Panel
Model BYFQ60B8W1
Color White
Dimensions (H × W × D) mm 55 × 700 × 700
Weight (Mass) kg 2.7
Airflow Rates
H
m³/min
(cfm)
12.0 (424) 12.0 (424)
L 8.0 (283) 8.0 (283)
Fan
Type Turbo Fan
Motor Output W 55
Speed Steps 2 Steps
Air Direction Control Horizontal, Downward
Running Current (Rated) A 0.49 0.45
Power Consumption (Rated) W 97 89
Power Factor (Rated) % 86.1 86.0
Temperature Control Microcomputer Control
Dimensions (H × W × D)

mm 260 (286) × 575 × 575
Packaged Dimensions (H × W × D) mm 370 × 687 × 674
Weight (Mass) kg 17.5
Gross Weight (Gross Mass) kg 21
Sound
Pressure
Level
H / L dB(A) 36.0 / 27.0
Sound Power Level dB 53.0 —
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm VP20 (O.D
φ
26 / I.D
φ
20)
Drawing No. 3D060409
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
