Outdoor Unit SiBE121123_A
27 Specifications
2. Outdoor Unit
50 Hz, 220 - 240 V
Note:
The data are based on the conditions shown in the table below.
Model
2MXS40H2V1B, 2MXS40H3V1B
2AMX40G2V1B, 2AMX40G3V1B
2MXS50H2V1B, 2MXS50H3V1B
2AMX50G2V1B, 2AMX50G3V1B
Cooling Heating Cooling Heating
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AGXD 2YC36BXD
Motor Output W 600 1,100
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.45 0.65
Refrigerant
Type R-410A R-410A
Charge kg 1.20 1.60
Airflow Rate
H
m³/min
36 32 37 34
M33323434
L30323434
H
cfm
1,271 1,130 1,306 1,200
M 1,165 1,130 1,200 1,200
L 1,059 1,130 1,200 1,200
Fan
Type Propeller Propeller
Motor Output W 50 50
Starting Current A 4.6 6.3
Dimension (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimension (H × W × D) mm 612 × 906 × 364 612 × 906 × 364
Weight (Mass) kg 38 42
Gross Weight (Gross Mass) kg 43 47
Sound Pressure Level dB(A) 47 48 48 50
Sound Power Level dB 62 — 63 —
Piping
Connection
Liquid mm φ 6.4 × 2
φ
6.4
×
2
Gas mm φ 9.5 × 2
φ
9.5
×
1,
φ
12.7
×
1
Drain mm φ 16.0
φ
16.0
Heat Insulation Both Liquid & Gas Pipes Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring 3 for Power Supply, 4 for Interunit Wiring
Max. Piping Length m
30 (for Total of Each Room) 30 (for Total of Each Room)
20 (for One Room) 20 (for One Room)
Min. Piping Length m 3 (for One Room) 3 (for One Room)
Amount of Additional Charge g/m 20 (20 m or more) 20 (20 m or more)
Max. Installation Height Difference m
15 (between Indoor Unit and Outdoor Unit) 15 (between Indoor Unit and Outdoor Unit)
7.5 (between Indoor Units) 7.5 (between Indoor Units)
Drawing No. 3D063350A 3D063351A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
