Daikin J-Series User Manual

Specifications SiBE041101
5 Specifications
1. Specifications
1.1 Cooling Only
50 Hz, 220 - 230 - 240 V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS20J2V1B FTXS25J2V1B FTXS35J2V1B
Outdoor Unit RKS20J2V1B RKS25J2V1B RKS35J2V1B
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.8) 2.5 (1.3 ~ 3.2) 3.5 (1.4 ~ 4.0)
Btu/h 6,800 (4,400 ~ 9,600) 8,500 (4,400 ~ 10,900) 11,900 (4,800 ~ 13,600)
kcal/h 1,720 (1,120 ~ 2,410) 2,150 (1,120 ~ 2,750) 3,010 (1,200 ~ 3,440)
Moisture Removal L/h 0.9 1.2 1.9
Running Current (Rated) A 2.6 - 2.5 - 2.4 3.1 - 2.9 - 2.8 4.4 - 4.2 - 4.0
Power Consumption
Rated (Min. ~ Max.)
W 450 (320 ~ 810) 535 (320 ~ 810) 860 (350 ~ 1,190)
Power Factor % 78.7 - 78.3 - 78.1 78.4 - 80.2 - 79.6 88.8 - 89.0 - 89.6
COP (Rated) W/W 4.44 (4.06 ~ 3.95) 4.67 (4.06 ~ 3.95) 4.07 (4.00 ~ 3.36)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 20 20 20
Max. lnterunit Height Difference m 15 15 15
Chargelessm101010
Amount of Additional Charge of
Refrigerant
g/m202020
Indoor Unit FTXS20J2V1B FTXS25J2V1B FTXS35J2V1B
Front Panel Color White White White
Airflow Rate
H
m³/min
(cfm)
9.4 (332) 10.8 (381) 11.4 (403)
M 7.4 (261) 7.9 (279) 8.7 (307)
L 5.5 (194) 5.2 (184) 5.8 (205)
SL 4.1 (145) 3.7 (131) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor OutputW232323
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.09 - 0.08 - 0.08 0.12 - 0.12 - 0.11
Power Consumption (Rated) W 18 - 18 - 18 18 - 18 - 18 26 - 26 - 26
Power Factor % 90.9 - 97.8 - 93.8 90.9 - 97.8 - 93.8 98.5 - 94.2 - 98.5
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366 289 × 870 × 366
Weight kg 9 9 10
Gross Weight kg 13 13 14
Operation
Sound
H / M / L / SL dB(A) 38 / 32 / 25 / 22 41 / 33 / 25 / 22 45 / 37 / 29 / 23
Sound Power dB(A) 54 57 61
Outdoor Unit RKS20J2V1B RKS25J2V1B RKS35J2V1B
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD 1YC23AEXD
Motor Output W 600 600 600
Refrigerant
Oil
Type FVC50K FVC50K FVC50K
Charge L 0.375 0.375 0.375
Refrigerant
Type R-410A R-410A R-410A
Charge kg 0.80 1.00 1.20
Airflow Rate
H
m³/min
(cfm)
36.2 (1,278) 33.5 (1,183) 36.0 (1,271)
SL 32.7 (1,155) 30.1 (1,063) 30.1 (1,063)
Fan
Type Propeller Propeller Propeller
Motor OutputW232323
Running Current (Rated) A 2.5- 2.4 - 2.3 3.0 - 2.8 - 2.7 4.3 - 4.1 - 3.9
Power Consumption (Rated) W 432 - 432 - 432 517 - 517 - 517 834 - 834 - 834
Power Factor % 78.5 - 78.3 - 78.3 78.3 - 80.3 - 79.8 88.2 - 88.4 - 89.1
Starting Current A 2.6 3.1 4.4
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 612 × 906 × 364 612 × 906 × 364
Weight kg 32 34 34
Gross Weight kg 35 38 38
Operation
Sound
H / SL dB(A) 46 / 43 46 / 43 48 / 44
Sound Power H dB(A) 61 61 63
Drawing No. 3D070569A 3D070570A 3D070571A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
