Daikin J-Series User Manual

Specifications SiBE041101
7 Specifications
1.2 Heat Pump
50 Hz, 220 - 230 - 240 V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS20J2V1B
Outdoor Unit
RXS20J2V1B
Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.8) 2.7 (1.3 ~ 4.3)
Btu/h 6,800 (4,400 ~ 9,600) 9,200 (4,400 ~ 14,700)
kcal/h 1,720 (1,120 ~ 2,410) 2,320 (1,120 ~ 3,700)
Moisture Removal L/h 0.9 —
Running Current (Rated) A 2.6 - 2.5 - 2.4 3.5 - 3.4 - 3.2
Power Consumption
Rated (Min. ~ Max.)
W 450 (320 ~ 810) 610 (310 ~ 1,290)
Power Factor % 78.7 - 78.3 - 78.1 79.2 - 78.0 - 79.4
COP (Rated) W/W 4.44 (4.06 ~ 3.95) 4.43 (4.19 ~ 3.64)
Piping
Connections
Liquid mm
φ
6.4
Gas mm
φ
9.5
Drain mm
φ
18.0
Heat Insulation Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 20
Max. lnterunit Height Difference m 15
Chargeless m 10
Amount of Additional Charge of
Refrigerant
g/m 20
Indoor Unit FTXS20J2V1B
Front Panel Color White
Airflow Rate
H
m³/min
(cfm)
9.4 (332) 9.9 (350)
M 7.4 (261) 8.2 (290)
L 5.5 (194) 6.6 (233)
SL 4.1 (145) 6.2 (219)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09
Power Consumption (Rated) W 18 - 18 - 18 21 - 21 - 21
Power Factor % 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366
Weight kg 9
Gross Weight kg 13
Operation
Sound
H / M / L / SL dB(A) 38 / 32 / 25 / 22 38 / 33 / 28 / 25
Sound Power dB(A) 54 54
Outdoor Unit RXS20J2V1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23AEXD
Motor Output W 600
Refrigerant
Oil
Type FVC50K
Charge L 0.375
Refrigerant
Type R-410A
Charge kg 0.80
Airflow Rate
H
m³/min
(cfm)
36.2 (1,278) 30.6 (1,080)
SL 32.7 (1,155) 28.5 (1,006)
Fan
Type Propeller
Motor Output W 23
Running Current (Rated) A 2.5 - 2.4 - 2.3 3.4 - 3.3 - 3.1
Power Consumption (Rated) W 432 - 432 - 432 589 - 589 - 589
Power Factor % 78.5 - 78.3 - 78.3 78.7 - 77.6 - 79.2
Starting Current A 3.5
Dimensions (H × W × D) mm 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364
Weight kg 32
Gross Weight kg 35
Operation
Sound
H / SL dB(A) 46 / 43 47 / 44
Sound Power H dB(A) 61 62
Drawing No. 3D070564A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
