Cooling Only SiBE121135_A
19 Specifications
1.2 Indoor Unit
Wall Mounted Type
50 Hz, 220 - 230 - 240 V
Model FTXS25J2V1B FTXS35J2V1B
Rated Capacity 2.5 kW Class 3.5 kW Class
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
10.8 (381) 11.4 (403)
M 7.9 (279) 8.7 (307)
L 5.2 (184) 5.8 (205)
SL 3.7 (131) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.12 - 0.12 - 0.11
Power Consumption (Rated) W 18 - 18 - 18 26 - 26 - 26
Power Factor (Rated) % 90.9 - 97.8 - 93.8 98.5 - 94.2 - 98.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight (Mass) kg 9 10
Gross Weight (Gross Mass) kg 13 14
Sound
Pressure
Level
H / M / L / SL dB(A) 41 / 33 / 25 / 22 45 / 37 / 29 / 23
Sound Power Level dB 57 61
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ 18.0 φ 18.0
Drawing No. 3D070570A 3D070571A
Model FTXS42J2V1B FTXS50J2V1B
Rated Capacity 4.2 kW Class 5.0 kW Class
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
11.3 (399) 11.6 (410)
M 9.0 (318) 9.2 (325)
L 6.8 (240) 7.0 (247)
SL 5.9 (208) 6.0 (212)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.11 - 0.11 - 0.11 0.12 - 0.12 - 0.11
Power Consumption (Rated) W 24 - 24 - 24 26 - 26 - 26
Power Factor (Rated) % 99.2 - 94.9 - 90.9 98.5 - 94.2 - 98.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight (Mass) kg 10 10
Gross Weight (Gross Mass) kg 14 14
Sound
Pressure
Level
H / M / L / SL dB(A) 45 / 39 / 33 / 30 46 / 40 / 34 / 31
Sound Power Level dB 61 62
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 12.7
Drain mm
φ 18.0 φ 18.0
Drawing No. 3D070572A 3D070573A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
