Daikin Super multi NX E Series User Manual

Cooling Only SiBE121135_A
21 Specifications
Ceiling Mounted Cassette Type
50 Hz, 230 V
 ( ) : dimension including control box
Model FFQ25B9V1B FFQ35B9V1B
Rated Capacity 2.5 kW Class 3.5 kW Class
Decoration
Panel
Model BYFQ60B8W1 BYFQ60B8W1
Color White White
Dimensions (H × W × D) mm 55 × 700 × 700 55 × 700 × 700
Weight (Mass) kg 2.7 2.7
Airflow Rate
H
m³/min
(cfm)
9.0 (318) 10.0 (353)
L 6.5 (230) 6.5 (230)
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Running Current (Rated) A 0.37 0.40
Power Consumption (Rated) W 73 84
Power Factor (Rated) % 85.8 91.3
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D)  mm 260 (286) × 575 × 575 260 (286) × 575 × 575
Packaged Dimensions (H × W × D) mm 370 × 687 × 674 370 × 687 × 674
Weight (Mass) kg 17.5 17.5
Gross Weight (Gross Mass) kg 21 21
Sound
Pressure
Level
H / L dB(A) 29.5 / 24.5 32.0 / 25.0
Sound Power Level dB 46.5 49.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm VP20 (O.D.
φ 26 / I.D. φ 20) VP20 (O.D. φ 26 / I.D. φ 20)
Drawing No. 3D060406 3D060408
Model FFQ50B9V1B FFQ60B9V1B
Rated Capacity 5.0 kW Class 6.0 kW Class
Decoration
Panel
Model BYFQ60B8W1 BYFQ60B8W1
Color White White
Dimensions (H × W × D) mm 55 × 700 × 700 55 × 700 × 700
Weight (Mass) kg 2.7 2.7
Airflow Rate
H
m³/min
(cfm)
12.0 (424) 15.5 (530)
L 8.0 (283) 10.0 (353)
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Running Current (Rated) A 0.49 0.61
Power Consumption (Rated) W 97 120
Power Factor (Rated) % 86.1 85.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D)  mm 260 (286) × 575 × 575 260 (286) × 575 × 575
Packaged Dimensions (H × W × D) mm 370 × 687 × 674 370 × 687 × 674
Weight (Mass) kg 17.5 17.5
Gross Weight (Gross Mass) kg 21 21
Sound
Pressure
Level
H / L dB(A) 36.0 / 27.0 41.0 / 32.0
Sound Power Level dB 53.0 58.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 12.7 φ 12.7
Drain mm VP20 (O.D.
φ 26 / I.D. φ 20) VP20 (O.D. φ 26 / I.D. φ 20)
Drawing No. 3D060410 3D040431
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
