SiBE121135_A Heat Pump
Specifications 28
2.2 Indoor Unit
Wall Mounted Type
50 Hz, 220 - 230 - 240 V
Model
FTXG25JV1BW FTXG25JV1BA
Cooling Heating Cooling Heating
Rated Capacity 2.5 kW Class 2.5 kW Class
Front Panel Color White Brushed Aluminium Panel
Airflow Rate
H
m³/min
(cfm)
8.8 (311) 9.6 (339) 8.8 (311) 9.6 (339)
M 6.8 (240) 7.9 (279) 6.8 (240) 7.9 (279)
L 4.7 (166) 6.2 (219) 4.7 (166) 6.2 (219)
SL 3.8 (134) 5.4 (191) 3.8 (134) 5.4 (191)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.12 - 0.11 - 0.11 0.09 - 0.08 - 0.08 0.12 - 0.11 - 0.11
Power Consumption (Rated) W 18 - 18 - 18 24 - 24 - 24 18 - 18 - 18 24 - 24 - 24
Power Factor (Rated) % 90.9 - 97.8 - 93.8 90.9 - 94.9 - 90.9 90.9 - 97.8 - 93.8 90.9 - 94.9 - 90.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 915 × 155 295 × 915 × 155
Packaged Dimensions (H × W × D) mm 285 × 1,003 × 377 285 × 1,003 × 377
Weight (Mass) kg 11 11
Gross Weight (Gross Mass) kg 15 16
Sound
Pressure
Level
H / M / L / SL dB(A) 38 / 32 / 25 / 22 39 / 34 / 28 / 25 38 / 32 / 25 / 22 39 / 34 / 28 / 25
Sound Power Level dB 56 57 56 57
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ 16.0 or φ 18.0 φ 16.0 or φ 18.0
Drawing No. 3D080182 3D080183
Model
FTXG35JV1BW FTXG35JV1BA
Cooling Heating Cooling Heating
Rated Capacity 3.5 kW Class 3.5 kW Class
Front Panel Color White Brushed Aluminium Panel
Airflow Rate
H
m³/min
(cfm)
10.1 (357) 10.8 (381) 10.1 (357) 10.8 (381)
M 7.3 (258) 8.6 (304) 7.3 (258) 8.6 (304)
L 4.6 (162) 6.4 (226) 4.6 (162) 6.4 (226)
SL 3.9 (138) 5.6 (198) 3.9 (138) 5.6 (198)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.13 - 0.12 - 0.12 0.16 - 0.15 - 0.14 0.13 - 0.12 - 0.12 0.16 - 0.15 - 0.14
Power Consumption (Rated) W 26 - 26 - 26 32 - 32 - 32 26 - 26 - 26 32 - 32 - 32
Power Factor (Rated) % 90.9 - 94.2 - 90.3 90.9 - 92.8 - 95.2 90.9 - 94.2 - 90.3 90.9 - 92.8 - 95.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 915 × 155 295 × 915 × 155
Packaged Dimensions (H × W × D) mm 285 × 1,003 × 377 285 × 1,003 × 377
Weight (Mass) kg 11 11
Gross Weight (Gross Mass) kg 15 16
Sound
Pressure
Level
H / M / L / SL dB(A) 42 / 34 / 26 / 23 42 / 36 / 29 / 26 42 / 34 / 26 / 23 42 / 36 / 29 / 26
Sound Power Level dB 60 60 60 60
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ 16.0 or φ 18.0 φ 16.0 or φ 18.0
Drawing No. 3D080185 3D080186
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
