Micro PDF417 Length Control
This feature specifies either variable length decoding or fixed length decod-
ing for this symbology.
Variable Length:
For variable length decoding, a minimum and maximum
length may be set.
Fixed Length:
For fixed length decoding, two different lengths may be set.
DEFAULT
Micro PDF417 Length Control = Variable Length
Micro PDF417 Length Control = Fixed Length
Micro PDF417 Set Length 1
Specifies one of the bar code lengths for Micro PDF417 Length Control.
Length 1 is the minimum label length if in Va
riable Length Mode, or the first
fixed length if in Fixed Length Mode. Length includes the bar code’s data
characters only. Characters can be set from 0001 to 0366 characters (pad
with zeroes) in increments of 01. Any value greater than 0366 will be con-
sidered to be 0366.
See page 281 for detailed instructions on setting this feature.
Select Micro PDF417 Length 1 Setting
To configure this feature, scan the ENTER/EXIT
PROGRAMMING MODE bar code above, then the bar
code at left followed by the digits from the Alphanu-
meric characters in
Appendix D, Keypad
repre-
senting your desired character(s). End by scanning
the
ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code t
o abort
and not save the entry string. You can then start
again at the beginning.
CANCEL
0001 = Length 1 is 1 Character
To Next Page
