Introduction
2 QuickScan
TM
QD2100
Chapter 12, Symbologies defines options for all symbologies and provides the program-
ming bar codes necessary for configuring these features.
Appendix A, Technical Specifications lists physical and performance characteristics, as
well as environmental and regulatory specifications. It also provides standard cable pin-
outs.
Appendix B, Standard Defaults references common factory default settings for imager
features and options.
Appendix C, LED and Beeper Indications supplies tables containing descriptions of the
functions and behaviors of the imager’s LED and Beeper indicators.
Appendix D, Sample bar codes offers sample bar codes of several common symbologies.
Appendix E, Keypad includes numeric bar codes to be scanned for certain parameter set-
tings.
Appendix F, Scancode Tables lists control character emulation information for Wedge
and USB Keyboard interfaces.
Manual Conventions
The following conventions are used in this document:
The symbols listed below are used in this manual to notify the imager of key issues or
procedures that must be observed when using the imager:
NOTE
Notes contain information necessary for properly diagnosing,
re
pairing and operating the imager.
CAUTION
The CAUTION symbol advises you of
actions that could dam-
age equipment or property.
References
Current versions of the Product Reference Guide (PRG), Quick Reference Guide
(QRG), the Datalogic Aladdin™ Configuration application, software/firmware and any
additional manuals, instruction sheets and utilities for this product can be downloaded
from the website listed on the back cover of this manual. Alternatively, printed copies or
product support CDs can be purchased through your Datalogic reseller.
