Datalogic QuickScan i QD2100 User Manual

Error Codes
Product Reference Guide 353
Error Codes
Upon startup, if the imager sounds a long tone, this means the imager has not passed its
automatic Selftest and has entered FRU
1
isolation mode. If the imager is reset, the se-
quence will be repeated. The following table describes the LED flashes/beep codes asso-
ciated with an error found.
1 Configuration
Contact Helpdesk for assis-
tance
2 Interface PCB
4 Imager Module
5 [Reserved]
6 Digital PCB
14 CPLD/Code Mismatch
1. Field Replaceable Unit (FRU)
NUMBER OF
LED
FLASHES/
BEEPS
ERROR CORRECTIVE ACTION

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
