Getting Started
8 QuickScan
TM
QD2100
Using the Programming bar codes
This manual contains feature descriptions and bar codes which allow you to reconfigure
your imager. Some programming bar code labels, like Resetting the Product Configu-
ration to Defaults on page 9
, require only the scan of that single label to enact the
change. Most of the programming labels in this manual, however, require the imager to
be placed in Programming Mode prior to scanning them. Scan an ENTER/EXIT bar
code once to enterProgramming Mode. Once the imager is in Programming Mode, you
can scan a number of parameter settings before scanning the ENTER/EXIT bar code a
second time, which will then accept your changes, exit Programming Mode and return
the imager to normal operation.
NOTE
There are some exceptions to the typical programming
seq
uence described above. Please read the description and
setting instructions carefully when configuring each given pro-
grammable feature.
Select the Interface Type
Upon completing the physical connection between the imager and its host, proceed di-
rectly to Interfaces on page 11 for information and programming for the interface type
the imager is connected to (for example: RS-232, Keyboard Wedge, USB, etc.) and scan
the appropriate bar code in that section to select your system’s correct interface type.
Configure Interface Settings
The imager is typically factory-configured with a set of default features standard to the
interface type you ordered. If after scanning the interface bar code from the Interfaces
section, your installation requires you to select options to further customize your imager,
turn to the appropriate section for your interface type as listed below:
• RS-232 ONLY Interface, starting on page 41
• Keyboard Interface, starting on page 67
• USB-OEM Interface, starting on page 81
• IBM 46XX Interface, starting on page 85
• Wand Emulation Interface, starting on page 91
Configure Other Features
If your installation requires different programming than the standard factory default set-
tings, the following sections of this manual allow configuration of non-interface-specific
settings you might require:
General Features
—
General Features includes programming for scanning, beeper and
LED indicators and other such universal settings.
Symbologies
—
Includes options concerning the bar code label types (symbologies).
These settings allow you to enable/disable symbologies, set label lengths, require check
digit, etc.
