INDICATION DESCRIPTION LED BEEPER
Power-up Beep
The imager is in the process of
powering-up.
Imager beeps four times at high-
est frequency and volume upon
po
wer-up.
Good Read Beep
A label has been successfully
scanned by the imager.
LED behavior for this indi-
cation is configurable via
the feature “Good Read:
When to Indicate”
The imager will beep once at
curren
t frequency, volume,
mono/bi-tonal setting and dura-
tion upon a successful label
scan.
ROM Failure
There is an error in the imager's
sof
tware/programming
Flashes
Imager sounds one error beep at
highest volume.
Limited Scanning
Label Read
Indicates that a host connection
is no
t established when the IBM
or USB interface is enabled.
N/A
Imager 'chirps' six times at the
highest frequency and current
volume.
Imager Active
Mode
The imager is active and ready
to scan.
The LED is lit steadily
a
a.
Except when in sleep mode or when a Good Read LED Duration other than 00 is selected
N/A
Imager
Disabled
The imager has been disabled
by the host.
The LED blinks continu-
ously
N/A
Green Spot is on
co
ntinuously
While in Stand Mode or Trigger
Obje
ct Sense mode the green
spot shall be on while in stand
watch state.
N/A N/A
Green Spot
a
flashes momen-
tarily
Upon successful read of a label,
the sof
tware shall turn the green
spot on for the time specified by
the configured value.
N/A N/A
Programming Mode -
The following indications ONLY occur when the imager is in Programming Mode.
Label Program-
ming Mode Entry
A valid programming label has
be
en scanned.
LED blinks continuously
Imager sounds four low fre-
quency beeps.
Label Program-
ming Mode
R
ejection of Label
A label has been rejected. N/A
Imager sounds three times at
lowest frequency
& current vol-
ume.
Label Program-
ming Mode
Accept
ance of
Partial Label
In cases where multiple labels
must be sca
nned to program one
feature, this indication acknowl-
edges each portion as it is suc-
cessfully scanned.
N/A
Imager sounds one short beep
at hi
ghest frequency & current
volume.
Label Program-
ming Mode
Accept
ance of
Programming
Configuration option(s) have
be
en successfully programmed
via labels and the imager has
exited Programming Mode.
N/A
Imager sounds one high fre-
quency beep and 4 low fre-
quency beeps followed by reset
be
eps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been scanned. N/A
Imager sounds two times at low
freque
ncy and current volume.
352 QuickScan
TM
QD2100
LED and Beeper Indications
