Scanning Features
Product Reference Guide 29
Scanning Features
Scan Mode
Selects the scan operating mode for the reader. Selections are:
Trigger Single — When the trigger is pulled, scanning is activated until one of the fol-
lowing occurs:
- Scanning Active Time has elapsed
- a label has been read
- the trigger is released
This mode is associated with typical handheld reader operation: when the trigger is
pulled, scanning starts and the product scans until the trigger is released, or a label is read,
or the maximum
Scanning Active Time has elapsed.
Trigger Hold Multiple — When the trigger is pulled, scanning starts and the product
scans until the trigger is released or Scanning Active Time has elapsed. Reading a label
does not disable scanning. Double Read Timeout prevents undesired multiple reads of
the same label while in this mode.
Trigger Pulse Multiple — When the trigger is pulled, continuous scanning is activated
until Scanning Active Time has elapsed or the trigger has been released and pulled
again. Double Read Timeout
1
prevents undesired multiple reads of the same label
while in this mode.
Flashing — The reader flashes
1
on and off regardless of the trigger status. Flash rate is
controlled by Flash On Time and Flash Off Time. When Flash is ON the imager reads
continuously. When Flash is OFF scanning is deactivated.
Always On — No trigger pull is required to read a bar code. Scanning is continually on.
If the trigger is pulled, the reader acts as if it is in Trigger Single Mode. Double Read
Timeout
1
prevents undesired multiple reads of the same label while in this mode.
Stand Mode — No trigger pull is required to read a bar code. Scanning is turned on au-
tomatically when an item is placed in reader’s field of view. If the trigger is pulled, the
reader acts as if it in single read mode. Double Read Timeout
1
prevents undesired mul-
tiple reads of the same label while in this mode.
Trigger Object Sense — This mode is similar to Stand Mode, except that a trigger pull
is required to activate the decoder.
1. Controlled by Flash On Time.

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
