Product Reference Guide 11
Chapter 3
Interfaces
Interface Selection
Each reader model will support one of the following sets of host interfaces:
General Purpose Models (5 volt supply)
RS-232
RS-232 OPOS
USB
Keyboard Wedge
Wand Emulation
Retail Point of Sale Models (4 to 14 volt supply)
RS-232
RS-232 OPOS
USB
IBM 46XX
Configuring the Interface
Scan the programming bar code from this section which selects the appropriate interface
type matching the system the reader will be connected to. Next, proceed to the corre-
sponding chapter in this manual (also listed in Table 1) to configure any desired settings
and features associated with that interface.
NOTE
Unlike some other programming features and options, inter-
face selections require that you scan only one programming
ba
r code label. DO NOT scan an ENTER/EXIT bar code prior to
scanning an interface selection bar code.
Some interfaces require the scanner to start in the disabled
st
ate when powered up. If additional scanner configuration is
desired while in this state, pull the trigger and hold it for five
seconds. The scanner will change to a state that allows pro-
gramming with bar codes.

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
