Codablock F
Product Reference Guide
323
Codablock F — cont.
Codablock F Set Length 2
This feature specifies one of the bar code lengths for Codablock F Length Control.
Length 2 is the maximum label length if in Variable Length Mode, or the second fixed
length if in
Fixed Length Mode. Length includes the bar code’s check, data, and full-
ASCII shift characters. The length does not include start/stop characters.
The length can be set from 3 to 255 characters. A setting of 0 specifies to ignore this
length (only one fixed length).
Follow these instructions to set this feature:
1. Determine the desired character length (from 3 to 255 — or 0 to ignore this length). Pad
the number with leading zeroes to yield three digits. For example: 0 = 000, 5 = 005, 20 =
020, etc.
2. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming
Mo
de.
3. Scan the bar code: SELECT CODABLOCK F LENGTH 2 SETTING.
4. Scan the appropriate three digits from the keypad in the Keypad Appendix that represent
the lengt
h setting which was determined in the steps above. You will hear a two-beep indi-
cation after the last character.
NOTE
If you make a mistake, before the la
st character scan the CANCEL bar
code to abort and not save the entry string. You can then start again at
the beginning.
5. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Programming
Mode.
This completes the procedure. See the table below for some examples of how to set this
feature.
Table 44. CODABLOCK Length 2 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
000 (Ignore This
Length)
007 Characters 015 Characters 050 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODABLOCK F LENG
TH 2 SETTING
4
Scan three Characters From
th
e Keypad Appendix
‘0’, ‘0’ and ‘0’ ‘0’, ‘0’ and ‘7’ ‘0’, ‘1’ and ‘5’ ‘0’, ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
To Next Page
