Dell 100 Series User Manual

Data network B nodes 4 - 8 wiring for 2U4N configuration in
a 3-phase cabinet
Use Figure 48 and table that follows to connect the data network B for nodes 4 - 8.
Note
Space on the page with Figure 48 does not provide enough space to illustrate cabling
of the maximum number of nodes in data network B, nodes 4 - 8. However, the table
that follows Figure 48 does provide all the source to destination cabling for the
maximum network.
Wiring Diagrams for a 2U4N Configuration in a Cabinet with 3-Phase Delta or 3-Phase Wye Power Distribution
Data network B nodes 4 - 8 wiring for 2U4N configuration in a 3-phase cabinet 111

Dell 100 Series Specifications

General

Processor	Intel Xeon E3-1200 series
Hard Drives	Up to 2 x 3.5" SATA HDD
Storage	SATA
Expansion Slots	1 x PCIe x16
Networking	Dual Gigabit Ethernet
