Right-Side Top Panel 107
22
Right-Side Top Panel
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
2
Open the PCI shroud. See "Opening the PCI Shroud" on page 45.
3
Remove the drive-bay shroud. See "Removing the Drive-Bay Shroud" on
page 47.
Removing the Right-Side Top Panel
1
Locate the screw that secures the right-side top panel to the chassis.
book.book Page 107 Wednesday, May 16, 2012 2:37 PM
