Media-Card Reader 41
6
Media-Card Reader
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
Removing the Media-Card Reader
1
Press the AlienHead on the front of your computer to lower the drive
panel.
2
Open the PCI shroud. See "Opening the PCI Shroud" on page 45.
3
Disconnect the FlexBay USB cable from the FLEXBAY connector on the
master I/O board. For more information on the location of the connector,
see "Master I/O Board Components" on page 21.
4
Lift and hold the securing tab and then push the FlexBay dock to slide it
out through the front of the computer.
book.book Page 41 Wednesday, May 16, 2012 2:37 PM
