Memory Fan 67
13
Memory Fan
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
WARNING: The heat sink may be very hot during normal operation. Provide
sufficient time for the heat-sink to cool before you touch it.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
Removing the Memory Fan
1
Disconnect the memory fan cable from the
MEM_FAN
connector on the
top lighting-board.
2
Pull the release tab towards the bottom of the computer and lift the
memory fan out of the chassis.
book.book Page 67 Wednesday, May 16, 2012 2:37 PM
