Front Bezel 129
27
Front Bezel
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
2
Open the PCI shroud. See "Opening the PCI Shroud" on page 45.
3
Remove the drive-bay shroud. See "Removing the Drive-Bay Shroud" on
page 47.
4
Remove the right-side top panel. See "Removing the Right-Side Top
Panel" on page 107.
5
Remove the right lighting-board. See "Removing the Right Lighting-
Board" on page 117.
6
Remove the right-side middle panel. See "Removing the Right-Side
Middle Panel" on page 113.
7
Remove the right-side bottom panel. See "Removing the Right-Side
Bottom Panel" on page 121.
Removing the Front Bezel
1
Remove the screws that secure the front bezel to the chassis.
2
Note the routing of the front-bezel cables and disconnect the front bezel
cables from the connectors on the master I/O board.
book.book Page 129 Wednesday, May 16, 2012 2:37 PM
