Theater-Lighting Batteries 93
18
Theater-Lighting Batteries
(ALX Chassis Only)
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
2
Open the PCI shroud. See "Opening the PCI Shroud" on page 45.
3
Remove the drive-bay shroud. See "Removing the Drive-Bay Shroud" on
page 47.
Removing the Theater-Lighting Batteries
1
Turn the drive-bay shroud over.
2
Open the theater-lighting battery compartment door.
NOTE: Your computer ships with two AA rechargeable batteries.
3
Remove the two batteries from the theater-lighting battery compartment.
book.book Page 93 Wednesday, May 16, 2012 2:37 PM
