Back Bezel 133
28
Back Bezel
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
2
Remove the power-supply unit. See "Removing the Power-Supply Unit" on
page 83.
3
Remove the processor liquid-cooling assembly. See "Removing the
Processor Liquid-Cooling Assembly" on page 71.
Removing the Back Bezel
1
Remove the screws that secure the security-lock panel to the chassis.
2
Pull the security-lock panel away from the chassis.
book.book Page 133 Wednesday, May 16, 2012 2:37 PM
