Power Supply 83
16
Power-Supply Unit
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
Removing the Power-Supply Unit
1
Lift and hold the tab on the power-supply cover, slide the power-supply
cover towards the back of the chassis, and remove the power-supply cover.
2
Lift the power-supply cover away from the chassis.
book.book Page 83 Wednesday, May 16, 2012 2:37 PM
