Processor 75
15
Processor
CAUTION: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 13.
For additional safety best practices information, see the Regulatory Compliance
Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
WARNING: Despite having a plastic shield, the processor liquid-cooling
assembly may be very hot during normal operation. Ensure that it has had
sufficient time to cool before you touch it.
2
Remove the processor liquid-cooling assembly. See "Removing the
Processor Liquid-Cooling Assembly" on page 71.
Removing the Processor
1
Press down and push the release lever away from the processor to release it
from the securing tab.
book.book Page 75 Wednesday, May 16, 2012 2:37 PM
