Dell Embedded Box PC5000 Service Manual

Removing the heat sink
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Prerequisites
1 Follow step 1 to step 6 in “Removing the back cover”.
2 Remove the PCI/PCIe card (if installed).
Procedure
1 Remove the screws that secure the chassis heat-sinks to the sides of the
chassis.
2 In sequential order (as indicated on the heat sink), remove the screws that
secure the heatsink to the CPU board.
101
