Removing the drives from the
hard-drive cage
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at
www.dell.com/regulatory_compliance.
CAUTION: Hard drives/solid-state drives are fragile. Exercise care when
handling the Solid-state/hard drive.
CAUTION: To avoid data loss, do not remove the hard drive/solid-state drive
while the Embedded Box PC is in sleep or on state.
Prerequisites
Follow step 1 to step 6 in “Removing the back cover”.
Procedure
NOTE: Embedded Box PC is shipped with hard drive, solid-state drive, or
both, depending on the conguration ordered.
1 Remove the screws that secure the top drive to the hard-drive cage.
27
