Replacing the top cover
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
1 Replace the power switch.
2 Place the top cover on the chassis and align the screw holes on the top cover
with the screw holes on the chassis.
3 Replace the screws that secure the top cover to the chassis.
4 Replace the hexagonal screws that secure the VGA port to the top cover.
5 Route the power-switch cable through the routing guides on the chassis.
6 Connect the power-switch cable to the connector on the system board.
Post-requisites
1 Replace the power connectors.
2 Replace the riser card.
3 Replace the CANbus cable.
4 Replace the PCI/PCIe card (if necessary).
5 Follow step 2 to step 8 in “Replacing the back cover”.
112
